Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT

  • Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT
  • Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT
  • Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT
  • Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT
Place of Origin China
Brand Name JINPAT
Certification ISO9001.ISO14000.CE.UL.FCC.RoHS
Model Number LPT012B-0602-HS-HT
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details Standard/On Request
Delivery Time 2 weeks ARO
Payment Terms T/T, C/C, Paypal
Supply Ability 500 pieces / week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Housing Material Engineering Plastic Contact Material Gold-Gold
Inner Diameter Φ12.7mm Working Speed 0~2000rpm
IP IP50 Working Humidity ≤60%RH
Serial Communication RS232, RS485, RS422, Etc. Universal Serial Bus USB2.0
Highlight

240VAC Through Hole Slip Ring

,

Gold Gold Through Hole Slip Ring

,

240VAC through bore slip rings
Product Description

Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT



electrical slip rings industrial,can integrate high frequency, fiber other signal

LPT series are through-bore slip rings (the center hole can pass through the drive shaft, gas-liquid passage; it can

also integrate high frequency, fiber, encoder, waveguide, gas and liquid and other joints). The use of advanced fiber

brush ensures reliable contact under extremely low friction. The center hole is available from 0 to 1000mm. The current

is from mA to 5000 amps. The voltage can be up to 10000 volts, which can fully meet different needs of transmission.



Electronic & Electruc

Mechanical

Circuits

Total

6CKT

Working Speed

0~2000rpm

Detail

6X2A

Inner Diameter

Φ12.7mm

Rating Voltage

240VAC

Contact Material

Gold-Gold

Dielectric Strength

500VAC@50Hz

Housing Material

Engineering plastic

Insulation Resistance

≥300MΩ@300VDC

Lead Wire Length

Stator:300mm

Rotor:300mm

Environment

Remarks

Working Temperature

-20°C~+125°C

Application

/

Working Humidity

≤60%RH

Other

/

IP

IP50

Note:"P" stands dor power, "S" stands for signal





LPT012B-0602-HS-HT-Outline Drawing






Industrial 240VAC Through Hole Slip Ring IP50 Engineering Plastic 6CKT 1
